Energy Efficient MAP Tray Sealer Packaging Machine 5KW For Fresh Fish

Brand Name:	China Xingyuan
Model Number:	QXY-1919
MOQ:	1
Price:	USD 6888-38888
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	1200 sets/Month

Detail Information

Product Description

Detail Information

Place of Origin:

China, Guangdong.

Certification:

ISO9001

Body Material:

304 Stainless Steel

Driving Mode:

Pneumatic

Working Press:

0.5Mpa~0.6Mpa

Power Consumption:

1.KW5-5KW

Customization:

Yes

Certificate:

CE ISO9001

Packaging Details:

Wooden Box

Highlight:

Fresh Fish Tray Sealer Packaging Machine

Energy Efficient Tray Sealer Packaging Machine

MAP Tray Sealer 5KW

Product Description

Plastic Box Packed Fresh Fish Meat Modified Atmosphere Packaging Machine

Product Overview

Our Plastic Box Packed Fresh Fish Meat Modified Atmosphere Packaging Machine utilizes advanced MAP technology to preserve freshness and extend shelf life while maintaining product quality and visual appeal. Ideal for seafood processors and distributors, this solution meets market demands with reliable performance.

Key Features

Superior freshness retention for fish products
Intuitive user interface for easy operation
Energy-efficient performance
Compact footprint suitable for various production environments
High-quality construction with food-grade materials

Technical Specifications

Brand Model	QXY-1919 Modified atmosphere fresh-keeping chain plate sealing machine
Type	Continuous, fully automatic
Packing 4 boxes (maximum size)	20014080 (mm)
Working air pressure	0.6-0.8 Mpa
Replacement rate	≥99%
Power supply	380V/50HZ 5KW
Shelf life	7-15 Days (varies by product type and storage conditions)
Mixed gas	Mixing of two gases
Program control	Mitsubishi PLC
Pneumatic part	AirTac
Machine casing	304 thickened stainless steel
Mold part	Fine grinding of anodized aluminum alloy acid-resistant aluminum mold
Mixer	MOCON, Denmark
Power air source	0.5-0.8MPa
Warranty	One-year warranty for the whole machine
Machine weight	1000 KG

Machine Functions and Configuration

Production capacity: 1200-1500 pieces/hour (one out of four configuration)
Complete workflow: automatic boxing, gas injection, hot pressing, date printing, and product output
Premium 304 stainless steel construction with food-grade 2B plate and brushed finish
Hand-polished surfaces with smooth edges for safety and durability
CNC-machined components for precision and long-term reliability
Food-grade stainless steel chain resistant to acids and alkalis
Sturdy welded steel frame with gantry milling for stability
Durable sealing mold with stainless steel and alumina construction
Servo motor drive with precise temperature control (±1°C)
Taiwan photoelectric eye tracking for perfect seal alignment
Delta PLC control with user-friendly interface and fault alarms
Compatible with various sealing materials (minimum 0.1mm thickness)
