Customized 304 Stainless Steel MAP Tray Sealer For Fresh Strawberry 220V 3KW

Brand Name:	China Xingyuan
Model Number:	LD672-CA
MOQ:	1
Price:	USD 68888-98888
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China, Guangdong.

Certification:

ISO9001

Body Material:

304 Stainless Steel

Driving Mode:

Pneumatic

Working Press:

0.5Mpa~0.6Mpa

Power Consumption:

1.KW5-5KW

Customization:

Yes

Certificate:

CE ISO9001

Packaging Details:

Wooden Box

Highlight:

Customized Map Sealer

Fresh Strawberry MAP Tray Sealer

MAP Tray Sealer 220V

Product Description

Custom Map Tray Sealer Automatic For Fresh Strawberry 220V/50HZ

Fresh Strawberry MAP Modified Atmosphere Packaging Production Line

Product Overview

This machine is a disc rotary modified atmosphere fresh-keeping sealing machine developed according to customer requirements. It can inject fresh-keeping gases in different proportions to extend the shelf life of food in a refrigerated environment. The sealing film is a roll film, which is automatically hot-pressed and sealed, and can automatically top the cup/box. It can seal 2 boxes, 4 boxes or more boxes at a time, saving human resources and improving production efficiency.

Technical Parameters

Model	LD672-CA Disk rotary type Modified Atmosphere Fresh-keeping Sealing Machine
Type	Modified Atmosphere Fresh-keeping Sealing Machine
Replacement Rate	≥99%
Rated Power	220V/50HZ 3KW
Shelf Life	7-15 Days (for reference only, depends on the product type and storage environment, also the operation workshop cleanliness)
Mixed Gas	Two gases mixed: 30%CO2 70%N2 or 20%CO2 80%O2
Program Control parts	Mitsubishi PLC
Pneumatic Parts	AirTac
Machine Casing	304 Thickened Stainless steel
Mold Parts	Fine grinding of anodized aluminum alloy acid-resistant aluminum mold
Mixer	MOCON Denmark
Power Air Source	0.4~0.6MPa
Warranty	One year warranty for the whole machine
Machine weight	500(KG)

Sealing Machine Functions and Configurations

One-out-Four. The mold can be replaced and is compatible with cups, bowls, boxes, bottles, barrels and cans of various shapes and sizes.
Production speed: One-out-one: 500-600 boxes/hour Production process: manual box placement, automatic injection of fresh-keeping gas in proportion, automatic film rolling and sealing, automatic printing of production date (optional), and automatic production of finished products.
Can be connected to the production line, unmanned operation, saving manpower and improving production efficiency.
Taiwan PLC program control, stable and reliable, the human-machine interface is a touch screen.
Classic digital display temperature control meter, temperature difference of plus or minus 5 degrees, good sealing effect.
Equipped with fault alarm and temperature alarm functions to ensure the sealing effect.
Taiwan photoelectric eye tracking, electrical integration.
Sealing material: consistent with the cup material, can be heated and bonded, plastic composite film or aluminum foil composite film, such as composite PP, composite PE, composite PET, composite PS, etc.
Air pressure range: 4-8KG/CM2
Adjustable temperature range: room temperature - 300 degrees
Power: 1000-2000W
Voltage: 110V or other voltages can be customized according to customer needs
Machine size: 1000*1000*1500MM (customized products, subject to actual conditions)
Machine frame structure: Made of high-quality stainless steel 304#, food-grade process 2B plate with brushed effect, dust-proof and rust-proof, acid-resistant and alkali-resistant; pure hand-polished and polished, fine workmanship.
Sealing system: constant temperature, intelligent temperature control, hot press sealing, sealing head is high-quality aluminum alloy, mold part: acid-resistant aluminum alloy mold (6061 aluminum alloy), CNC processing, high precision, anodized anti-oxidation treatment, no deformation, corrosion resistance, high hardness, long life. Non-sand cast aluminum!
Cup dispensing system: electric eye induction, base cylinder lifts up; upper cylinder connects to the pull-out mechanism to pull out.
Net weight: 500KG
Packing method: wooden box or wooden frame
Accessories: 2 10A fuses, one instruction manual, one hexagonal wrench, one cross screwdriver, one paper tube.

Main Configuration List

Operation screen: Taiwan Weiluntong touch screen human-machine interface
PLC: Delta PLC
Frequency Converter: Delta
Motor: Taili motor
Divider: Lianrui divider
Cylinder: Taiwan Yadeke cylinder
Solid state: Taiwan Yangming
Power supply: Delta
Relay: France Schneider
Mold assembly: Aluminum alloy oxidation
Disc assembly: Aluminum alloy oxidation

Payment Method

After the contract is signed, 50% of the total contract amount will be paid as a deposit. The remaining 50% can be paid after the equipment is completed and can be inspected on-site or confirmed by video. After the equipment is inspected and qualified, the payment will be released and the equipment will be delivered.

Delivery Period

10-15 days

Warranty Policy

The machine is guaranteed for one year and provides lifetime service.
