Beef Ball Modified Atmosphere Packaging Machines 1.5KW-5KW High Speed 220V/50HZ

Beef Ball Modified Atmosphere Packaging Machines 1.5KW-5KW High Speed 220V/50HZ

Brand Name: China Xingyuan
Model Number: LD641
MOQ: 1
Price: USD 12888~14988
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: 1000 sets/Month
Detail Information
Place of Origin:
China, Guangdong.
Certification:
ISO9001
Body Material:
304 Stainless Steel
Driving Mode:
Pneumatic
Working Press:
0.5Mpa~0.6Mpa
Power Consumption:
1.KW5-5KW
Customization:
Yes
Certificate:
CE ISO9001
Packaging Details:
Wooden Box
Highlight:

Beef Ball Modified Atmosphere Packaging Machines

,

High Speed Modified Atmosphere Packaging Machines

,

50HZ modified atmosphere packaging equipment

Product Description
Beef Ball MAP Packaging Machine 1.5KW-5KW High Speed 220V/50HZ
This high-speed multi-row modified atmosphere packaging machine extends food shelf life in refrigerated environments without preservatives. It features vacuum or gas-flush capabilities, accepts roll or sheet films, and performs automatic boxing, gas replacement, sealing, and unloading. With secondary sealing for reliability, date printing, and multi-box sealing capacity, it significantly improves production efficiency while maintaining food freshness.
Technical Parameters
Brand Model QXY-1919 Modified atmosphere fresh-keeping chain plate sealing machine
Type Modified Atmosphere fresh-keeping sealing machine
Packing 2 boxes (maximum size) 300*190*80 (mm)
Packaging speed Modified Atmosphere 4~5 times/min
General packaging 5*6 times/min
Packing 4 boxes (maximum size) 220*160*80 (mm)
Working air pressure 0.6 Mpa
Replacement Rate ≥99%
Rated Power 220V/50HZ 3KW
Shelf Life 7-15 Days (Depending on product type, storage environment and workshop cleanliness)
Mixed Gas Mixing of two gases
Program Control parts Mitsubishi PLC
Pneumatic parts AirTac
Machine casing 304t Thickened Stainless Steel
Mold Parts Fine grinding of anodized aluminum alloy acid-resistant aluminum mold
Mixer MOCON Denmark
Power Air Source 0.4~0.6MPa
Warranty One year warranty for the whole machine
Machine weight 1000(KG)
Beef Ball Modified Atmosphere Packaging Machines 1.5KW-5KW High Speed 220V/50HZ 0 Beef Ball Modified Atmosphere Packaging Machines 1.5KW-5KW High Speed 220V/50HZ 1
Machine Functions and Configuration
  • One out of four production capability
  • Production speed: 1200-1500 pieces/hour
  • Automated workflow: boxing, gas injection, hot pressing, date printing, and finished product output
  • 304 stainless steel construction with food-grade 2B plate and brushed finish
  • Hand-polished surfaces with no sharp corners for safety
  • CNC-machined components for precision and durability
  • Food-grade stainless steel 304 chain, water-washable and corrosion-resistant
  • Heavy-duty steel frame with gantry-milled surfaces for stability
  • Stainless steel + alumina sealing mold for fast heat conduction
  • Servo motor drive with ±1°C temperature control
  • Taiwan photoelectric eye tracking for precise pattern alignment
  • Delta PLC control with touchscreen interface and fault alarms
  • Compatible with various sealing materials (minimum 0.1mm thickness)
  • Air pressure range: 4-8KG/CM²
  • Temperature range: 0-250°C
  • Power: 5000-8000W
  • Voltage: 380V 50HZ
  • Customizable dimensions
  • Wooden box packaging
Electrical Components
  • Human-machine interface: Taiwan Weilun
  • PLC: Taiwan Delta
  • Solenoid valve: Taiwan AirTac
  • Air switch: France Schneider
  • Master cylinder: Taiwan AirTac
  • Switch power supply: Taiwan Delta
  • Temperature control solid state: South Korea
  • Drive motor: Taiwan servo
  • Temperature control meter: Japan Fuji
  • Repeater: France Schneider
  • Circuit breaker: France Schneider
  • Frequency converter: Taiwan Delta
  • Host structure: 3.0mm thick 304 stainless steel frame
  • Sealing mold: 6061 aluminum alloy, acid-resistant
  • Sealing hot plate: aluminum plate
Customization Options
We customize equipment based on tray specifications and production requirements. Modified atmosphere packaging preserves food's original qualities while extending shelf life through advanced food technology.
Applications
  • Fast food lunch boxes
  • Fresh poultry, meat, seafood
  • Cooked food, pickles
Ideal For:
  • Food processing plants
  • Meat processing facilities
  • Fruit/vegetable processors
  • Supermarket fresh food operations
  • Restaurants and food service providers
Operating Principle
The machine replaces box air with preservative gas, controlled via electrical system and cylinders. The process includes:
  1. Box placement
  2. Switch activation
  3. Mold positioning
  4. Air removal
  5. Gas injection (N₂, O₂, CO₂)
  6. Sealing and film cutting
  7. Finished product ejection
Gas Mixing Options
Custom gas mixers available for different food types. Upgrade to ternary gas mixer available.
Safety Instructions
  • Always connect grounding wire before operation
  • Keep hands clear during operation
  • Use emergency stop button when needed
  • Power off when installing sealing film
  • Gradually increase temperature for first-time sealing
  • Ensure machine is level on solid surface
  • Regularly lubricate guide columns
  • Daily cleaning of conveyor belt and motor
  • Contact service for electrical issues
Core Components
  • Control System: Mitsubishi PLC, Weiluntong touchscreen
  • Pneumatics: Taiwan AirTac cylinders and valves
  • Mixing System: Denmark MOCON
  • Molds: Sandblasted anodized aluminum with Teflon coating
Ordering Information
  • Payment: 50% deposit, 50% upon inspection
  • Lead Time: 20-25 days
  • Warranty: 1 year with lifetime service
