Fresh Locking Modified Atmosphere Packaging Machine 3KW For Sealerall Braised Duck'S Neck

Brand Name:	China Xingyuan
Model Number:	LD672-CA
MOQ:	1
Price:	USD 12888~14988
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	1000 sets/Month

Detail Information

Product Description

Detail Information

Place of Origin:

China Guangdong.

Certification:

ISO9001

Body Material:

304 Stainless Steel

Driving Mode:

Pneumatic

Working Press:

0.5Mpa~0.6Mpa

Power Consumption:

1.KW5-5KW

Customization:

Yes

Certificate:

CE ISO9001

Packaging Details:

Wooden Box

Highlight:

Fresh Locking Modified Atmosphere Packaging Machine

Modified Atmosphere Packaging Machine 3KW

Fresh Locking map packing machine

Product Description

Sealerall Braised Duck's Neck Modified Atmosphere Packaging Machine

This high-speed multi-row modified atmosphere fresh-locking chain plate sealing machine extends food shelf life in low-temperature refrigerated environments without preservatives. It supports vacuum or fresh-keeping gas filling, with optional roll or sheet film sealing. Features include automatic boxing, gas replacement, sealing, date printing, and unloading, with capacity for four or more simultaneous box seals to maximize efficiency.

Technical Parameters

Brand Model	LD672-CA Disk rotary type Modified Atmosphere Fresh-keeping Sealing Machine
Type	Modified Atmosphere fresh-keeping sealing machine
Packing 2 boxes (maximum size)	30019080 (mm)
Packaging speed	Modified Atmosphere 4~5 times/min General packaging 5*6 times/min
Packing 4 boxes (maximum size)	22016080 (mm)
Working air pressure	0.6 Mpa
Replacement Rate	≥99%
Rated Power	220V/50HZ 3KW
Shelf Life	7-15 Days (Reference only, depends on product type, storage environment and workshop cleanliness)
Mixed Gas	Mixing of two gases
Program Control parts	Mitsubishi PLC
Pneumatic parts	AirTac
Machine casing	304t Thickened Stainless Steel
Mold Parts	Fine grinding of anodized aluminum alloy acid-resistant aluminum mold
Mixer	MOCON Denmark
Power Air Source	0.4~0.6MPa
Warranty	One year warranty for the whole machine
Machine weight	1000(KG)

Machine Functions and Configuration

One out of four production capacity
Production speed: 1000-1200 pieces/hour (one out of four configuration)
Workflow: Automatic boxing, fresh-keeping gas injection, hot pressing/sealing, date printing, and finished product output
High-quality stainless steel 304 construction with food-grade industrial 2B plate and brushed effect
Hand-polished with fine workmanship, small chassis interface, and no sharp corners
CNC machine-added parts for precision and long-term stable operation
Food-grade stainless steel 304 chain, acid/alkali resistant and water-washable
Thick steel structure frame with gantry milling machine planing for stability
Stainless steel + alumina sealing mold for durability and fast heat conduction
Servo motor drive with ±1°C digital temperature control for reliable sealing
Taiwan photoelectric eye tracking for precise pattern alignment
Delta PLC program control with Taiwan HMI for fault monitoring
Compatible with various sealing materials (plastic composite film, aluminum foil, etc.)

Electrical Accessories

Human-machine interface: Taiwan Weilun
PLC: Taiwan Delta
Solenoid valve: Taiwan AirTac
Air switch: France Schneider
Master cylinder: Taiwan AirTac
Temperature control: Japan Fuji
Drive motor: Taiwan servo

Non-Standard Customization

We customize equipment based on packaging tray specifications and production requirements. Modified atmosphere packaging preserves food's original taste, color, and nutrition while extending shelf life when combined with proper food technology.

Applications

Packaging Types:

Fast food lunch boxes
Fresh poultry, meat, seafood
Cooked food and pickles

Ideal For:

Food processing plants and distribution centers
Meat and frozen food processing facilities
Supermarket fresh food operations
Restaurants and bakery operations

Working Principle

The machine replaces box air with fresh-keeping gas. The electrical system controls cylinders to execute mold operations, gas replacement, sealing, and film cutting. Standard sealing involves mold closure and film cutting.

Gas Mixing

Gas mixers are provided based on food characteristics. Upgrade to ternary gas mixer available.

Usage Precautions

Connect grounding wire before use
Keep hands clear during operation
Use emergency stop button when needed
Power off during film installation
Gradually increase temperature for first-time sealing
Ensure level machine placement
Regularly lubricate guide columns
Daily cleaning maintenance required
Contact professionals for electrical issues

Main Configuration

Control: Mitsubishi PLC with Weiluntong touch screen
Pneumatics: Taiwan AirTac cylinders and valves
Mixing system: Denmark MOCON
Mold: Sandblasted anodized aluminum alloy with Teflon coating

Payment & Delivery

50% deposit upon contract signing
50% balance after on-site/video inspection
Delivery period: 20-25 days
Warranty: 1 year with lifetime service
